Marca: KingSong
Modelo: 18L - DISPONIBLE
La linea mas grande de KingSong es en aro 18", probado y testeado a más no poder. Potente, fiel, elegante, simple, incansable y cumplidor.
CARACTERISTICAS:
1. Manillar telescopico integrado. Portable y maniobrable.
2. Panel de luz LED lateral controlable. 6 programas con full espectro de colores a elección. Indicador LED de estado de bateria.
3. Luz frontal blanca y luz trasera de freno color rojo para una conduccíon segura. (5w led + 2 x1w luz de freno). Funcionan para ambas direcciones.
4. Ventilador radiador intercooler 12V, velocidad de ventilacion varia de acuerdo a la temperatura para superar los rendimientos de viaje.
5. Bateria 1036wh , rinde hasta 105 kilometros x carga.
6. App permite modificar varias caracteristicas.
- Velocidad instantanea
- Estatus bateria
- Temperatura motor
- gps, social media, blokeo anti robo, clave, luces, tipo de conduccion, seguridad, limites de velocidad, bocina, parlantes, musica, actualizaciones etc etc.
7. 2200w high speed motor (NUEVO MOTOR ACTUALIZADO MARZO 2021)
8. 4 Hi-Fi Bluethoot parlantes, 12V power amplifier
9. Doble Puerto de carga USB. (Solo se provee un cargador por equipo, el segundo es adicional)
10. Sensor de Subida ( sensor que permite detener la rueda cuando jalas el manillar, detiene el motor para facilitar la manipulacion del KingSong)
11. Monitoreo real de temperatura, permite tener máxima seguridad de conducción.
------
| Model | KS-18L |
| Top Speed | Around 40km /h, top speed support decode to 50km/h after 200km total mileage( Default setting: 1st beeping at 18km/h, 2nd beeping at 19km/h, pedal tilt at 20km/h) |
| Mileage | Around 1036Wh, 105km |
| Maximum Gradibility | Around 35° |
| Battery | Rated Power： DC 74V
Top Charging Voltage： DC 84V
Rated Capacity：1036Wh
Smart BMS with balance and protect overshoot/ over discharge/ overcurrent/ short circuit/ overheating function, support monitoring the battery conditions via KingSong APP |
| Operating Temperature | -10℃/+60℃ |
| Max Load | 120kg |
| Charger Voltage | Input AC 80~240 V ，output DC 84V、1.5A |
| Charging Time | 1036Wh about 14h(one charger around 10hrs, double chargers 6 hrs,you may buy another charger as there are double charging ports) |
| Rated Power | 2200w |
| Max Power | 5000w |
| Color | Rubber black, White |
| Dimension & Weight |
| Dimension | 590mm（H） x495mm(L） X 180mm（W） |
| Package Size(mm) | 760mm(H) x 565mm(L) x 260mm( W) |
| Pedal Altitude (from ground) | 160mm |
| Tire Size | 18inch Diameter 480mm |
| Weight | Around 24kg |
| EUC Port | Charging port x 2; Switch port x1; Light sensor port x1; USB discharge port x2 (one port support USB plug and play ) |
| Protective Measures |
| Tilt Protection | 45° left and right side. ( Motor stalls when over 45° )
Place the machine vertically on the ground will restart automatically, no need to restart manually |
| Speed Limit Protection | Beep alarm or voice alarm when exceed limit speed |
| Low Battery Protection | Low battery protection activated on 30% battery, speed will decreases linearly; when the battery is lower than 5%, voice alarm for charge, when battery at 0%, the front part of the pedal will rise to decelerate until full stop |
| Alarm & Features |
| Swith On/Off | Short press power key: turn on
Long press: hear a click then turn off |
| Battery Indicate | Led shows battery level when EUC power on at rest |
| Sound Notification | EUC fall down, buzzer beep alarm for 5 seconds,
Voice alarm：
1. Low battery alarm: Your device is in low battery, please charge it. (Please charge the device ASAP)
2. Over speed alarm: Pls decelerate. (Please slow down at once)
3. Connect Bluetooth: Bluetooth is connected.
4. Disconnect Bluetooth: Blutooth is disconnected.
5. Over voltage alarm: Be caution, over voltage. (Please pay attention, this is dangerous alarm! )
6. Over heated alarm: Be caution, over power. (Please pay attention, at this condition power is about to reach the limit )
7. Buzzer beeping |
| Package |
| Standard Accessories | Charger x1，user mannuel x1，warranty card x1，certificate x1 |
